Describe Product
Specifications
Specification:
|
Optical |
|
|
Wavelength |
1100~1600nm |
|
Reflection Loss |
45dB (Min.) |
|
Connector |
SC/APC |
|
Input Power |
-18~+3dBm |
|
RF |
|
|
Frequency Bandwidth |
5~65MHz or 5~200MHz |
|
Reflection Loss |
≥16dB |
|
Flatness |
±0.75dB |
|
Output Level |
90dBuV (standard), 115dBuV (max) |
|
TP Level |
-20dB |
|
Link Performance |
NPR≥30dB, NPR dynamic range≥20dB |
|
General |
|
|
Dimension |
483mm×370mm×44mm |
|
Power Supply |
90VAC~265VAC |
|
Weight |
4Kg |
|
Power Consumption |
≤18W |
|
Operating Temperature |
0 °C ~+50 °C |
