Describe Product
Specifications
|
Parameters Type |
Unit |
SC、LC |
|
|
SM |
|||
|
UPC |
APC |
||
|
Insertion Loss |
dB |
≤0.2 |
≤0.2 |
|
Return Loss |
dB |
≥50 |
≥60 |
|
Repeatability |
db |
≤0.2 |
|
|
Changeability |
dB |
≤0.2 |
|
|
Fiber tube type |
Mm |
2 or Other on request |
|
|
Fiber Length |
m |
|
|
|
Ferrule Material |
-- |
Ceramic for SM, Bronze for MM |
|
|
Operating Temp |
℃ |
-30 ~ +75 |
|
|
Storage Temp |
℃ |
-30 ~ +85 |
|
